Dry air shaking table

Dry air shaking table,China dry concentrate shaker table

Air tables,also called dry shaking air table,dry shaking table,none water shaker table, It is a screening equipment that separates materials based on their density and weight differences. This equipment belongs to dry separation equipment and is mainly used in industrial working conditions that require high precision and stability.


Application

Used for sorting over 200 types of materials, including gold, platinum, zinc, tungsten, pickaxe, tin, antimony, copper, niobium, tantalum, titanium, zirconium, garnet sand, glass, plastic, aluminum powder, quartz sand, asbestos, mica, kaolin, sepiolite, and diamond.

Widely used in fields such as chemical engineering, mining, metallurgy, building materials, and waste resource recycling.

Working principle

This equipment adopts dry separation method, which selects materials with relatively light or heavy specific gravity based on the difference in specific gravity of the materials. The specific principle is that the raw materials are distributed on the surface of the sieve bed, and under the action of wind, the materials are suspended. The heavy materials sink and the light materials float up. At the same time, the sieve bed moves back and forth, transporting the heavy materials at the bottom to the high end of the sieve bed, while the light materials at the surface slide down to the low end of the sieve bed, thus causing separation of the raw materials.

Parameter of the Dry air shaking table

What is the difference with wet shaking table

Air dry shaking table use a shaking motion similar to that of shaking table and gemini table, but instead of water, air is used to separate heavy minerals.The table deck is covered with a porous material and air is blown up through the deck from a chamber underneath.
